DESCRIPTION OF THE DOOR PANEL
25
Sound modules
EL63 PLUS2/
EL642/PLUS
EL632/R5
EL642/R5
EL655
EL651
EL620/2PLUS
Access control module
N3301/AL
, .
coded module and access control
, video door entry system with colour television camera, 3 wires + COAX.
Door panel component assembly drawing.
Aluminium panel
Electronic
modules
Frame modulesEmbedding boxes
Description of the door panel
.
Description of the Nexa modular door panel:
Grille module:
N1000/AL
N1110/AL 1P.
N2220/AL 2P.
Clip-on covers: 60xx
Access control module:
N3301/AL
Nexa module separator (x2)
Fixing screws for clip-on covers (x4)
Side profile (x2)
Side profile Door panel joining bar
*
Fixing screws for embedding box (x2)
Door panel joining bar: Enables 2 door panels to be joined.
, audio door entry system, 4 common wires.
, video door entry system with colour television camera, 5 common wires.
, audio door entry system, 5 common wires.
Button module
EL610A
EL610D
,
for 5 individual or 10 double buttons (4+n devices).
, .for 5 individual or 10 double buttons
*
Button modules
N3XXX
, audio door entry system, 4+n.
, audio door entry system, several access doors, 4+n+CO.
, .audio door entry system, 2 wires
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
