golmar Nexa - Page 64

64
WIRING DIAGRAMS
Combined with Nexa Modular / Nexa Stainless Steel panels:
Door panels with EL620/2PLUS
sound module
N3301
access control module
FA-Plus/C
power supply unit
C2NC1 NC2
CN1
P
~ ~
SEC
+
-
PRI
~~
CN1
+
BUS
C1NA1 NA2
PL1 PL2
- -
CV1CV2 +12
Main
C2NC1 NC2
CN1
P
~ ~
C1NA1 NA2
PL1 PL2
-
AUDIO AND VIDEO DOOR ENTRY SYSTEM - ACCESS CONTROL
