Grandstream Networks DP730 Administration Guide

P a g e | 76
DP752/DP730/DP722 Administration Guide
Version 1.0.11.4
HTTP/HTTPS
Password
Enters password to authenticate with HTTP/HTTPS server.
Phonebook XML
Server Path
Indicates server path to download XML phonebook file. This field could be IP
address or URL, with up to 256 characters.
Phonebook
Download Interval
Sets interval to send XML phonebook download requests (in minutes). If set to 0,
automatic download is disabled. Valid range is 5 to 720. Default is 5 minutes.
Manual XML Phonebook Management
Import XML
Phonebook
Upload: Uploads manually global XML phonebook file to the base station.
Delete: Clears global XML phonebook file in the base station.
Export XML
Phonebook
Downloads global XML phonebook from the base station in .xml format.
Global Phonebook LDAP Settings
Global Phonebook
Type
Selects type of global phonebook to use.
If set to XML, DP752 will use the configuration in Global Phonebook XML Settings
page. If set to LDAP, DP752 will use configuration in Global Phonebook LDAP
Settings page.
LDAP Phonebook Settings
LDAP protocol
Chooses LDAP or LDAPS (LDAP over TLS) protocol. Default is LDAP.
Server Address
Configures IP address or domain name of the LDAP server.
Port
Determines LDAP server port. Default is 389.
Base
Indicates the location in the directory where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
Binds "Username" for querying LDAP servers. Some LDAP servers allow
anonymous binds in which case the setting can be left blank.
Password
Binds "Password" for querying LDAP servers. The field can be left blank if the LDAP
server allows anonymous binds.
LDAP Filter
LDAP filter to limit which contacts are fetched from the server. LDAP statement to
limit which contacts are fetched from the server. Statement must be in parenthesis.

Grandstream Networks DP730 Specifications

General

Brand	Grandstream Networks
Model	DP730
Category	Cordless Telephone
Language	English
