A-2
Appendix
Appendix A Main Specifications
Item CE5000-120AP
CPU 32-bit
Configuration Grit-rolling
Drive system Digital servo
Maximum cutting area 1164 mm x 50 m
Maximum guaranteed cutting area
1164 mm x 3 m*
1
Compatible media
Media widths 160 to 270, 300 to 400, 440 to 540, 580 to 680, 710 to 810, 850 to 950,
990 to 1090, 1120 to 1220 mm (the effective cutting/plotting area is the
maximum obtainable area for the corresponding medium width)
Up to 1180 mm when roll media (2-inch core) is used
Maximum roll outer diameter 190 mm
Media types Fine quality paper for apparel patterns (64 to 130 g/m
2
)
Roll media diameter: 2-inch, 3-inch
Maximum cutting speed 60 cm/s
Specifiable cutting speeds 1 to 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60 cm/s
Cutting force 20 to 300 gf, 31 levels
Mechanical resolution 0.005 mm
Programmable resolution GP-GL: 0.1/0.05/0.025/0.01 mm, HP-GL
TM
*
3
: 0.025 mm
Repeatability precision
Mechanical precision Within 0.1 mm/3 m*
2
Guaranteed precision Within ±0.5 mm/3 m, up to a maximum of five consecutive pages*
1
(cutter pen/plotter pen exchange precision is also included)
No. of pens mountable 2
Compatible cutter blade type Supersteel
Compatible pen type Water-based fiber-tip pens, Oil-based ballpoint pen
Interfaces RS-232C/USB 2.0 (Full speed)
Buffer capacity 2 MB
Command modes GP-GL, HP-GL
TM
*
3
(control-panel selectable)
Display panel LCD (16 characters x 1 row)
Rated power supply 100 to 240 VAC, 50/60 Hz
Power consumption 100 VA
Operating environment 10 to 35°C, 35 to 75% RH (non-condensing)
Conditions for guaranteed precision
18 to 28°C, 45 to 65% RH (non-condensing)
External dimensions (W x D x H) Approx. 1487 x 1020 x 1189 mm
Weight Approx. 43 kg
*1:When the following Graphtec-specified conditions have been met:
• Graphtec-specified paper must be used for cutting/plotting.
•“PAPER LOAD: 2” must be specified for the PAPER LOAD setting and “UNTIL: 180 seconds” for the PAPER
READY TIME setting.
• After five pages have been cut/plotted consecutively, the paper must be reloaded.
• If expansion or contraction of the paper due to temperature and/or humidity changes has occurred during
a cutting or plotting operation, the following margins of error are added to the repeatability precision value:
0.1 mm/°C, 0.3 mm/10% RH.
*2:The precision specification is the precision that was obtained when Graphtec’s mylar film was used to
measure the mechanical precision. Please note that as only fine quality pattern paper can be used with this
device, the precision may differ slightly.
*3:HP-GL™ is a registered trademark of Hewlett-Packard Company.
