Function Settings and Operations
4-23
4.19 Setting the OFFSET FORCE (Initial Cutting Force)
This function specifies the cutting force to be applied during initial blade control for checking the cutter-blade
direction at the start of operation. This is used to control the rotation of the cutter-blade tip during initial blade
control when thick media is cut, and is therefore not necessary to specify for media of regular thickness. The
initial setting is "4." Increasing this setting increases the cutting force.
(1) Press the (PAUSE) key to switch to PAUSE mode.
(2) Press the (NEXT) or (PREV.) key until the following menu is displayed.
ADVANCED FUNC.
(3) Press the (ENTER) key, and then press the (NEXT) or (PREV.) key
until the following menu is displayed.
OFFSET FORCE
(4) Press the (ENTER) key to display the offset-force setting menu.
OFFSET FORCE 4
Use the or key to select the required value within the range of "1" to
"31", and then press the (ENTER) key to confirm.
To cancel the selection, press the (NEXT) or (PREV.) key.
(5) Press the (PAUSE) key to cancel PAUSE mode.
CHECKPOINT
This setting is retained in the internal memory even when the power is turned off.
BLADE WARE SETUP
CUT LINE PAT.
TANGENTIAL
INIT. B
PEN UP SPEED
INITIAL FEED
AUTO PRE FEED
SETUP MENU
TEST
FEED&CUT
PEN UP/DOWN
ADVANCED FUNC.
CLEAR BUFFER
