FC9000-UM-251-9370 7-50
7 DISASSEMBLY AND REASSEMBLY
Conrming the exible cable wiring from the cam sensor board to the main board
The exible cable has a right side and a wrong side, connect the exible cable correctly as shown in the
picture below.
Cam sensor exible cable
Cam sensor exible cable
Cam sensor board
Conrm the printed side,
which is facing to the right.
Conrm the printed side,
which is facing to the up.
Main board
Conrming the exible cable wiring (Y exible cable) from the Y relay board to the main board
The exible cable has a right side and a wrong side, connect the exible cable correctly as shown in the
picture below.
Y relay board
Y Flexible cable
Conrm the printed
side, which is facing to
the up.
Y Flexible cable
Conrm the printed
side, which is
facing to the down.
Main board
