7 DISASSEMBLY AND REASSEMBLY
Conrming the exible cable wiring from the control panel board to the main board
The exible cable has a right side and a wrong side, connect the exible cable correctly as shown in the
picture below.
[Main board side]
Control panel exible cable
Control panel exible cable
Conrm the printed side,
which is facing to the up.
Main board
[Control panel board side]
Control panel exible cable
Conrm the printed side,
which is facing to the down.
Conrm the printed side,
which is facing to the down.
Control panel board
