Gree U-Match 5 Series - Removal of Front Panel

GREE U-Match 5 SERIES UNIT SERVICE MANUAL
118
Removal of front panel
Note: Before removing the front panel, make sure power is cut off.
Step Picture Work instruction
5. Remove the right side plate.
 Unscrew the screws that
connect the right side plate
to the electric box and the
screws around the right side
plate.
6. Install the right side plate
 Screw up the screws around
the right side plate. Be
careful to handle well the
clasps at the bottom of the
right side plate.
7. Install the front panel.
 Install the front panel by
mounting on 6 clasps on its
both sides. Please note that
there is one screw on the
lower right side.
8. Install the grill.
 Attach the grill back in place
and tighten up the screws.
