GREE U-Match 5 SERIES UNIT SERVICE MANUAL
135
Removal of fan and motor
Note: Before removing the fan, make sure power is cut off.
Step Picture Work instruction
3. Remove motor.
 Use a screwdriver to
unscrew the bolt of motor.
Note: Motor wire should be
first removed from the
electric box.
4. Install the motor.
 Replace with a new motor.
Then tighten up the screw
bolt.
5. Install the fan.
 Install the fan in place. Put
on the gasket and use a
wrench to secure the screw
nut.
Note: After installing the fan,
turn the fan by hand to see
if it can run normally. If not,
please check for the
reason.
6. Install the grill.
 After replacing the motor,
use a screwdriver to tighten
up the screw bolt that
secures the motor.
