GREE U-Match 5 SERIES UNIT SERVICE MANUAL
208
No. Material Name Finished Product Code Remarks
4 Right Side Plate 26909400071 1
5 Right Side Plate 26909400074 1
6 Installation Supporting Frame(right) 01809402 1
7 Axial Bush 10542704 2
8 Evaporator Assy 011001060183 1
9 Rotating Shaft 3 26909430 6
10 Guide Louver 200004500426 2
11 Crankshaft 200023000001 2
12 Stepping Motor 1521240206 2
13 Display Board 30294000009 1
14 Base Plate Assy 011007060032 1
15 Clapboard Sub-Assy 01249400019 1
16 Left Side Plate 26909400070 1
17 Installation Supporting Frame(Left) 01809401 1
18 Main Board 300002060226 1
19 Terminal Board 42018000551 1
20 Terminal Board 42000100000202 1
21 Electric Box Assy 100002003030 1
22 Support Of Motor Bearing 01792408 2
23 O-Gasket of Bearing 76512404 1
24 Propeller Housing(Lower) 200230000001 4
25 Roller Wheel 700004000001 2
26 Joint Slack 73018731 2
27 Brushless DC Motor 15709400005 1
28 Centrifugal Fan 103003000001 4
29 Propeller Housing(Upper) 200230000002 4
30 Rear Side Plate Sub-Assy 017051000006 1
31 Filter Sub-Assy 111001000001 3
32 Drainage Pipe Sub-Assy 05235434 1
33 Swing Lever 10582009 4
34 Air Louver 200007000001 20
35 Supporter(Guide Louver) 26909400076 3
36 Water Tray 200063000002 1
37 Top Cover 01269400013P 1
38 Front Grill Sub-Assy 26909400066 4
