Grizzly G0750G User Manual

-98-
Model G0750G (Mfg. Since 11/12)
Apron Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P07090501 GEAR 60T 550 P07090550 OIL SIGHT GLASS M20-1.5
502 PRP05M ROLL PIN 5 X 30 551 PRP91M ROLL PIN 5 X 35
503 P0750G0503 GEAR 40T 552 P07090552 COMPRESSION SPRING
504 P0750G0504 PINION 13T 553 PSTB004 STEEL BALL 3/16
505 PSS121M SET SCREW M6-1 X 16 PILOT POINT 554 P07090554 PLUG
506 P07090506 BUSHING 555 PRP16M ROLL PIN 3 X 25
507 PCAP26M CAP SCREW M6-1 X 12 556 P0750G0556 DOWEL PIN 5 X 25
508 PW03M FLAT WASHER 6MM 557 PSS02M SET SCREW M6-1 X 6
509 P07090509 GEAR 18T 558 P07090558 LEVER HUB
510 P07090510 IDLER SHAFT 559 P07090559 HALF NUT HANDLE M8-1.25 X 6
511 PCAP33M CAP SCREW M5-.8 X 12 561 P07090561 GASKET
512 PORP020 O-RING 19.8 X 2.4 P20 562 P07090562 FRONT COVER
513 P07090513 SHAFT 563 P07090563 FEED INDICATOR PLATE
514 P07090514 WORM GEAR 564 P07090564 TAPER PIN 5 X 20
515 P0750G0515 WORM GEAR FLAT WASHER 6MM 565 P07090565 SPLINE SHAFT
516 PCAP26M CAP SCREW M6-1 X 12 566 P07090566 CHANGE LEVER M8-1.25 X 20
517 P07090517 INTERLOCK LEVER 567 P07090567 COMPRESSION SPRING
518 PCAP02M CAP SCREW M6-1 X 20 568 P07090568 BRACKET
519 PSS04M SET SCREW M6-1 X 12 569 PCAP48M CAP SCREW M6-1 X 35
520 PB42M HEX BOLT M5-.8 X 20 570 P07090570 PLUG
521 P07090521 HALF NUT GIB 571 P07090571 WORM SHAFT
522 PB04M HEX BOLT M6-1 X 10 572 PCAP01M CAP SCREW M6-1 X 16
523 PSS29M SET SCREW M6-1 X 35 573 P07090573 CLUTCH GEAR 63T
524 PN01M HEX NUT M6-1 574 P07090574 CLUTCH GEAR 40T
525 P07090525 DIAL INDICATOR 575 P07090575 COMBO CLUTCH GEAR 30T
525-1 P07090525-1V2 THREAD DIAL LABEL 576 P07090576 PLUG
526 P07090526 HALF NUT RETAINER 2-PC 577 PLUBE002M BALL OILER 8MM TAP-IN
527 P07090527 HALF NUT ASSEMBLY 578 P07090578 SHOULDER BOLT M8-1.25 X 8
528 P07090528 DOWEL PIN 8 X 16 579 P07090579 HANDWHEEL HANDLE
529 P07090529 WORM 580 PFH38M FLAT HD SCR M6-1 X 16
530 P07090530 CAM SHAFT 581 P0750G0581 HANDWHEEL FLAT WASHER 6MM
531 PSS118M SET SCREW M5-.8 X 16 CUP POINT 582 P07090582 HANDWHEEL
532 PN06M HEX NUT M5-.8 583 P07090583 GRADUATED DIAL
536 PCAP05M CAP SCREW M8-1.25 X 50 584 PCAP38M CAP SCREW M5-.8 X 25
537 P07090537 THREAD DIAL BODY 585 P07090585 SUPPORT HUB
538 P07090538 HELICAL GEAR 24T 586 P07090586 GASKET
539 PW01M FLAT WASHER 8MM 587 PK34M KEY 5 X 5 X 20
540 PN03M HEX NUT M8-1.25 588 P07090588 GEARED SHAFT 14T
545 PRIV014M STEEL FLUTED RIVET 2 X 5 589 PCAP13M CAP SCREW M8-1.25 X 30
547 P07090547V2 THREAD DIAL CHART 590 P07090590 TAPERED PIN 8 X 40
548 P07090548 DRAIN PLUG 1/8" NPT 591 P0750G0591 APRON CASE
549 P07090549 HALF NUT INDICATOR PLATE
