Grizzly G0750G User Manual

Model G0750G (Mfg. Since 11/12)
-87-
READ ELECTRICAL SAFETY
ON PAGE 82!
Control Panel Wiring
CONTROL PANEL
NC
NO
HUILONG
LA103
10A 660V
HUILONG
LA103,10A 660V
HUILONG
LA103
10A 660V
X2
X2
X1
X1
HUILONG
XD103
110V
NO
1
2
4
6
5
3
0
0
0
E-STOP
BUTTON
POWER START/ON
BUTTON W/LIGHT
JOG
BUTTON
POWER
LIGHT
LA103
110V
To Electrical
Cabinet
Page 84
Figure 148. Control panel wiring.
Power Start/ON
Button w/Light
Jog Button
Power
Light
E-Stop
Button
