Grizzly G0776 - Section 9: Parts - Headstock Parts List; Headstock Component Part Numbers

-98-
Model G0776 (Mfd. Since 7/14)
Stand/Brake/Coolant Pump
Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P07760001 SPLASH GUARD 34 P07760034 LEFT CABINET COVER (SIDE)
2 P07760002 FLAT WASHER 6MM 35 P07760035 CAP SCREW M10-1.5 X 30
3 P07760003 CAP SCREW M6-1 X 10 36 P07760036 HEX NUT M10-1.5
4 P07760004 CHIP PAN 37 P07760037 EXTENSION SPRING
5 P07760005 CAP SCREW M6-1 X 20 38 P07760038 SPRING RETENTION PIN
6 P07760006 WORKLIGHT BRACKET 39 P07760039 CAP SCREW M6-1 X 40
7 P07760007 CAP SCREW M5-.8 X 15 40 P07760040 BRAKE HARD STOP
8 P07760008 WORK LAMP 41 P07760041 BRAKE PEDAL SHAFT (LEFT)
8-1 P07760008-1 HALOGEN BULB 50W 24V 42 P07760042 ROLL PIN 5 X 28
9 P07760009 HEX NUT M6-1 44 P07760044 ROLL PIN 5 X 40
10 P07760010 PHL HD SCR M6-1 X 10 45 P07760045 BRAKE ROCKER
11 P07760011 STAND PLATE BRACKET (R) 46 P07760046 SET SCREW M6-1 X 12 CONE-PT
12 P07760012 LEFT CABINET 47 P07760047 LIMIT SWITCH COVER
13 P07760013 STAND PLATE BRACKET (L) 48 P07760048 LIMIT SWITCH YBLXW-5/11N1
14 P07760014 STAND PLATE 49 P07760049 PHLP HD SCR M4-.7 X 40
15 P07760015 RIGHT CABINET 50 P07760050 BRAKE RETAINING COLLAR
16 P07760016 LIFTING HOLE COVER 51 P07760051 BRAKE PEDAL SHAFT (RIGHT)
17 P07760017 CAP SCREW M4-.7 X 6 52 P07760052 BRAKE PEDAL
18 P07760018 COOLANT HOSE COLLAR 53 P07760053 COOLANT CHUTE
19 P07760019 COOLANT FITTING 54 P07760054 LOCK CONNECTOR
20 P07760020 COOLANT NOZZLE 55 P07760055 COOLANT TANK
21 P07760021 COTTER PIN 3 X 16MM 56 P07760056 COOLANT PIPE FITTING
22 P07760022 BRAKE LINKAGE (UPPER) 57 P07760057 COOLANT PUMP DALEI DOB-12/40 0.2HP 220V
23 P07760023 ROCKER 58 P07760058 RIGHT CABINET COVER (SIDE)
24 P07760024 ROCKER SHAFT 59 P07760059 FLAT WASHER 10MM
25 P07760025 REMOVABLE CHIP TRAY 60 P07760060 EXT RETAINING RING 8MM
26 P07760026 HEX NUT M4-.7 61 P07760061 ROCKER PIN
27 P07760027 FLAT WASHER 4MM 62 P07760062 KEY 8 X 8 X 20
28 P07760028 CHIP TRAY HANDLE BRACKET 63 P07760063 CAP SCREW M6-1 X 10
29 P07760029 PHLP HD SCR M4-.7 X 10 64 P07760064 BRAKE LINKAGE (MIDDLE)
30 P07760030 CHIP TRAY HANDLE 65 P07760065 BRAKE LINKAGE (LOWER)
31 P07760031 PULLEY BRAKE ASSEMBLY 25 X 125 66 P07760066 SPINDLE PULLEY
32 P07760032 CAP SCREW M8-1.25 X 16 67 P07760067 LEFT CABINET COVER (REAR)
33 P07760033 FENDER WASHER 8MM
