Grizzly G0776 - Machine Data Sheet: Specifications; Product and Shipping Dimensions; Electrical Requirements and Specifications

-8-
Model G0776 (Mfd. Since 7/14)
The information contained herein is deemed accurate as of 11/16/2017 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3
Model G0776
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0776 13" X 40" GUNSMITHING LATHE WITH DRO
Product Dimensions:
Weight............................................................................................................................................................ 1280 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 74-1/2 x 31 x 58 in.
Footprint (Length x Width)............................................................................................................... 70-1/2 x 19-3/4 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight............................................................................................................................................................ 1370 lbs.
Length x Width x Height....................................................................................................................... 74 x 30 x 60 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Full-Load Current Rating....................................................................................................................................... 8.5A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length.............................................................................................................................................. 6.5 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type.......................................................................................................................... NEMA 6-15
Switch Type............................................................................................ Control Panel w/Magnetic Switch Protection
Motors:
Spindle
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps........................................................................................................................................................... 8.5A
Speed................................................................................................................................................ 1720 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings........................................................................................................... Shielded & Permanently Sealed
Main Specifications:
Operation Info
Swing Over Bed.................................................................................................................................... 13.70 in.
Distance Between Centers........................................................................................................................ 40 in.
Swing Over Cross Slide.......................................................................................................................... 7.71 in.
Swing Over Saddle............................................................................................................................... 11.75 in.
Swing Over Gap................................................................................................................................... 18.50 in.
Maximum Tool Bit Size............................................................................................................................. 5/8 in.
Compound Travel.................................................................................................................................. 3-1/4 in.
Carriage Travel.......................................................................................................................................... 33 in.
Cross Slide Travel................................................................................................................................. 5-7/8 in.
Machine Data Sheet
