REF PART # DESCRIPTION REF PART # DESCRIPTION
801 P07760801 HANDWHEEL HANDLE 819 P07760819 TAILSTOC CASTING
802 P07760802 SHOULDER SCREW M10-1.5 X 10, 11 X 63 820 P07760820 QUILL LOCK LEVER BASE M8-1.25 X 32
803 P07760803 SET SCREW M5-.8 X 25 821 P07760821 QUILL LOCK LEVER HANDLE M8-1.25 X 8
804 P07760804 FLAT WASHER 8MM 822 P07760822 TAILSTOCK LOCK LEVER SHAFT
805 P07760805 HANDWHEEL 120MM DIA DISHED 823 P07760823 TAILSTOCK LOCK LEVER HANDLE M8-1.5 X 10
806 P07760806 LEAF SPRING 824 P07760824 DOWEL PIN 5 X 30MM
807 P07760807 TAILSTOCK GRADUATED COLLAR 825 P07760825 CAM SLEEVE
808 P07760808 CAP SCREW M6-1 X 16 826 P07760826 SET SCREW M10-1.5 X 50 DOG-PT
809 P07760809 QUILL LEADSCREW BRACKET 827 P07760827 TAILSTOCK LOCKING SCREW
810 P07760810 BALL OILER 6MM PRESS-IN 828 P07760828 TAILSTOCK BASE
811 P07760811 THRUST BEARING 51102 829 P07760829 TAILSTOCK BLOCK M12-1.75 X 100
812 P07760812 KEY 4 X 4 X 15 830 P07760830 TAILSTOCK CLAMP BLOCK
813 P07760813 TAILSTOCK QUILL LEADSCREW 831 P07760831 HEX NUT M12-1.75
814 P07760814 TAILSTOCK QUILL LOCK NUT M8-1.25 832 P07760832 FLAT WASHER 12MM
815 P07760815 KEY 4 x 4 x 6 833 P07760833 FENDER WASHER 12MM
816 P07760816 CAP SCREW M4-.7 X 12 834 P07760834 COMPRESSION SPRING
817 P07760817 CAM 835 P07760835 FENDER WASHER 12MM
818 P07760818 TAILSTOCK QUILL 836 P07760836 CAP SCREW M8-1.25 X 15 HOLLOW
