Grizzly G0776 - Section 9: Parts - Cross Slide Parts List; Cross Slide Component Part Numbers

-108-
Model G0776 (Mfd. Since 7/14)
Apron Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P07760501 APRON CASTING 541 P07760541 DOWEL PIN 5 X 33
502 P07760502 HEX BOLT M8-1.25 X 30 542 P07760542 GEAR 43T
503 P07760503 FLAT WASHER 8MM 543 P07760543 STEEL BALL 6MM
504 P07760504 KEY 5 X 5 X 36 544 P07760544 COMPRESSION SPRING
505 P07760505 WORM 545 P07760545 SET SCREW M8-1.25 X 8
506 P07760506 WORM BRACKET 546 P07760546 SHAFT
507 P07760507 HALF NUT 547 P07760547 GEARED SHAFT 10T
508 P07760508 CAP SCREW M6-1 X 40 548 P07760548 FEED SELECTION LEVER
509 P07760509 HEX NUT M6-1 549 P07760549 FEED SELECTION BRACKET
510 P07760510 HALF NUT HOUSING 550 P07760550 CAP SCREW M6-1 X 45
511 P07760511 APRON GIB 551 P07760551 APRON DRAIN PLUG M10-1.5 X 1
512 P07760512 HEX BOLT M6-1 X 25 552 P07760552 FLAT HD SCR M6-1 X 12
513 P07760513 SET SCREW M6-1 X 15 553 P07760553 FLANGE WASHER 6MM
514 P07760514 SPACER 554 P07760554 GEAR 24T
515 P07760515 THREAD DIAL BRACKET 555 P07760555 KEY 5 X 5 X 10
516 P07760516 THREAD DIAL INDICATOR 556 P07760556 SHAFT
517 P07760517 CAP SCREW M6-1 X 60 557 P07760557 CAP SCREW M5-.8 X 10
518 P07760518 GEAR 16T 558 P07760558 LOCATING BLOCK
519 P07760519 CAP SCREW M6-1 X 15 559 P07760559 ROLL PIN 5 X 25
520 P07760520 SHAFT 560 P07760560 GEAR 14T
521 P07760521 EXT RETAINING RING 18MM 561 P07760561 SHAFT CAP
522 P07760522 SET SCREW M6-1 X 6 CONE-PT 562 P07760562 GEARED SHAFT
523 P07760523 GEAR 21T 563 P07760563 BALL OILER 6MM PRESS-IN
524 P07760524 DOWEL PIN 5 X 10MM 564 P07760564 SUPPORT HUB
525 P07760525 CAM SHAFT 565 P07760565 GRADUATED DIAL
526 P07760526 HEX BOLT M6-1 X 10 566 P07760566 LEAF SPRING
527 P07760527 FLAT WASHER 6MM 567 P07760567 HANDWHEEL 140MM DIA SPOKED
528 P07760528 SHAFT 568 P07760568 HANDWHEEL HANDLE
529 P07760529 LOCATING BLOCK 569 P07760569 SHOULDER SCREW M12-1.75 X 15, 13 X 64
530 P07760530 PULLEY 570 P07760570 FLANGE WASHER 9MM
531 P07760531 HALF NUT LEVER 571 P07760571 CAP SCREW M8-1.25 X 24 HOLLOW
532 P07760532 TAPER PIN 5 X 40 572 P07760572 SET SCREW M5-.8 X 30 DOG-PT
533 P07760533 LEVER HUB 573 P07760573 SHAFT
534 P07760534 SIGHT GLASS M22-1.5 574 P07760574 GEAR 25T
535 P07760535 PHLP HD SCR M5-.8 X 12 575 P07760575 GEARED SHAFT 11T
536 P07760536 RACE 576 P07760576 SPACER
537 P07760537 ROLL PIN 4 X 30 577 P07760577 ROLL PIN 5 X 30
538 P07760538 ROLL PIN 4 X 50 578 P07760578 GEAR 50T
539 P07760539 GEAR 25T 579 P07760579 SHAFT CAP
540 P07760540 GEAR 51T
