Grizzly G0776 - Section 8: Wiring - Motor and Control Wiring; Spindle Motor Wiring Diagram; Coolant Pump, Brake, and DRO Wiring

Model G0776 (Mfd. Since 7/14)
-93-
Spindle Motor Wiring
CBB65
20MFD
450VAC
CD60
150MFD
250VAC
PE
Spindle Motor
Start Capacitor
Run Capacitor
V2
V2
W1
W1
W2
V1
U1
U1
U2
Ground
Figure 151. Spindle motor junction box.
Figure 152. Start capacitor. Figure 153. Run capacitor.
To Electrical
Cabinet
Page 91
