Function of analog output
• Actual speed
The reading is a percentage of the rated speed.
• Actual value
The reading is a percentage of the range between
the minimum
and maximum value.
• Resulting setpoint
The reading is a percentage of the external setpoint
range.
• Motor load
The reading is a percentage of the range between 0
and 200 % of the maximum permissible load at the
actual speed.
• Motor current
The reading is a percentage of the range between 0
% and 200 % of the rated current.
• Limit 1 exceeded and Limit 2 exceeded
This function is typically used for monitoring of
secondary parameters in the system. If the limit is
exceeded, an output, a warning or an alarm is
activated.
• Flow rate
The reading is a percentage of the range between 0
and 200 % of the nominal flow.
Factory setting
See section 24. Factory settings.
Signal
range
[V, mA]
Actual speed
[%]
0 100 200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA
Signal
range
[V, mA]
"Actual value"
Sensor
min
Sensor
max
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal
range
[V, mA]
Resulting setpoint
[%]
0 100
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal
range
[V, mA]
Motor load
[%]
0100
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal
range
[V, mA]
Motor current
[%]
0 100 200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA
Signal
range
[V, mA]
Limit-exceeded function
Output not
active
Output active
0-10 V 0 V 10 V
0-20 mA 0 mA 20 mA
4-20 mA 4 mA 20 mA
Signal
range
[V, mA]
Flow rate
[%]
0 100 200
0-10 V 0 V 5 V 10 V
0-20 mA 0 mA 10 mA 20 mA
4-20 mA 4 mA 12 mA 20 mA

Grundfos CME Specifications

General

Liquid temperature range	0 °C to +60 °C
Maximum operating pressure	10 bar
Series	CME
Frequency	50/60 Hz
Max Pressure	10 bar
Pump Type	Centrifugal
Material	Stainless steel
Applications	pressure boosting, irrigation
Pumped liquid	Clean water
Approvals	CE
Max Liquid Temperature	60°C
Power Supply	1-phase or 3-phase
