English (GB)
53
13.40 Warning log
This menu contains a list of logged warnings from
the product. The log shows the name of the warning,
when the warning occurred and when it was reset.
13.41 Assist
This menu consist of a number of different assist
functions which are small guides that take you
through the steps needed to set the pump.
13.42 Assisted pump setup
This menu guides you through the following:
Setting of pump
• Selection of control mode. See page 28.
• Configuration of feedback sensors.
• Adjusting the setpoint. See page 28.
• Controller settings. See page 40.
• Summary of settings.
Example of how to use the Assisted pump setup
for setting up the pump to constant pressure:
Grundfos GO
1. Open the Assist menu.
2. Select Assisted pump setup.
3. Select control mode "Constant pressure" (Const.
pressure).
4. Read the description for this control mode.
5. Select which analog input to use as sensor input.
6. Select sensor function according to where the
sensor is installed in the system. See fig. 39 on
page 34.
7. Select electrical input signal according to the
sensor specifications.
8. Select measuring unit according to the sensor
specifications.
9. Set the minimum and maximum sensor range
values according to the sensor specifications.
10. Set the desired setpoint.
11. Set the gain and integral time of the controller.
See section 13.12 "Controller" (Controller
settings).
12. Type the desired pump name.
13. Check the summary of settings and confirm
them.
Advanced control panel
1. Open the Assist menu.
2. Select Assisted pump setup.
3. Select control mode Const. pressure.
4. Select which analog input to be used as sensor
input.
5. Select the measured parameter which is to be
controlled. See fig. 39 on page 34.
6. Select measuring unit according to the sensor
specifications.
7. Set the minimum and maximum sensor range
values according to the sensor specifications.
8. Select electrical input signal according to the
sensor specifications.
9. Set the desired setpoint.
10. Set the gain and integral time of the controller.
See section 13.12 "Controller" (Controller
settings).
11. Check the summary of settings and confirm them
by pressing [OK].
13.43 Setup, analog input
This menu is only available in the advanced control
panel.
This menu guides you through the following:
Setup, analog input
• "Analog inputs" 1 to 3. See page 33.
• "Pt100/1000 input" 1 and 2. See page 35.
• "Adjusting the setpoint". See page 28.
•"Summary".
Pump variant Assisted pump setup
CME ●
CRE, CRIE, CRNE,
SPKE, MTRE
●
Pump variant Setup, analog input
CME ●
CRE, CRIE, CRNE,
SPKE, MTRE
●
