English (GB)
66
24. Factory settings
● Function is enabled.
❍
Function is disabled.
- Function is not available.
Settings
CRE, CRIE, CRNE, SPKE, MTRE
Function
description
on page
With
factory-fitted
sensor
Without
factory-fitted
sensor
CME
Setpoint
75 % of sensor
range
75 % of sensor
range
75 % of sensor
range
28
Operating mode Normal Normal Normal 28
Control mode
"Constant
pressure"
"Constant
pressure"
"Constant
pressure"
28
Pipe filling function Not active Not active Not active 47
"Buttons on product" Active Active Active 50
"Stop function" (Low-flow stop
function)
Not active Not active Not active 45
"Controller" (Controller settings) ●●●
40"Ti" 0.5 0.5 0.5
"Kp" 0.5 0.5 0.5
Operating range 50-100 % 50-100 % 50-100 % 41
Ramps
48Ramp-up 1 second 1 second 1 second
Ramp-down 3 seconds 3 seconds 3 seconds
"Number" (Pump number) - - - 49
"Radio communication" Active Active Active 49
"Analog input 1" 4-20 mA Not active Not active
33"Analog input 2" Not active Not active Not active
"Analog input 3"
1)
Not active Not active -
1)
"Pt100/1000 input 1"
1)
Not active Not active -
1)
35
"Pt100/1000 input 2"
1)
Not active Not active -
1)
"Digital input 1" External stop External stop External stop
35
"Digital input 2"
1)
Not active Not active -
1)
"Digital in/output 3" Not active Not active Not active
37
"Digital in/output 4"
1)
Not active Not active -
1)
"Pulse flowmeter"
❍❍❍
48
Predefined setpoints 0 bar 0 % 0 % 43
Analog output
1)
"Speed" "Speed" -
1)
38
External setpoint function Not active Not active Not active 41
"Signal relay 1" "Alarm" "Alarm" "Alarm"
38
"Signal relay 2" "Running" "Running" "Running"
Limit 1 exceeded Not active Not active Not active
44
Limit 2 exceeded Not active Not active Not active
