4 ADVANCED OPERATION EXAMPLE
APS-1102A
4-13
c) Select measurement display
Select one form among RMS, AVG, or PEAK as the measured current and voltage values to be
displayed.
To select a measurement display, select “MEASURE” in the MISC menu .
 Operation steps
1. Press the or key to move the cursor to the icon.
ENTERCANCEL
Cursor
2. Press the
ENTER
key to display the MISC menu.
Press the or key to move the cursor to “MEASURE”.
ENTERCANCEL
3. Press the
ENTER
key to display the selection box.
ENTERCANCEL
Selection box
