Reference Commands
:REF<X>:DISPlay ........................................................109
:REF<X>:TIMebase:POSition ....................................109
:REF<X>:TIMebase:SCALe ........................................110
:REF<X>:OFFSet ........................................................110
:REF<x>:SCALe .......................................................... 111
:REF<X>:DISPlay
Description
Sets or queries whether a reference waveform will
be shown on the display. A reference waveform
must first be saved before this command can be
used.
Syntax
:REF<x>:DISPlay { OFF| ON | ? }
Parameter
<X>
Reference waveform 1, 2, 3, 4.
OFF
Turns the selected reference
waveform off
ON
Turns the selected reference
waveform on
Return parameter
Returns the status of the selected reference
waveform. (OFF, ON).
Example
:REF1:DISPlay ON
Turns on reference1 (REF 1) on the display.
:REF<X>:TIMebase:POSition
Description
Sets or returns the selected reference waveform
time base position.
Syntax
:REF<X>:TIMebase:POSition { <NRf> | ?}
Related
commands
:REF<X>:DISPlay
Set
Query
Set
Query
