COMMAND DETAILS
143
Parameter
<X>
REF 1, 2, 3, 4
<string>
The string must be no more than 8
characters and only contain
alphanumeric characters in addition
to period, dash and underscore
characters. The string must be
enclosed in double quotes, “string”.
Return parameter
<string>
Returns the label for the selected
reference waveform. No return
indicates that there has not been a file
label assigned for the selected
reference waveform.
Example1
:REF1:LABel "REF1_lab"
Sets the REF1 label as "REF1_lab".
Example2
:REF1:LABel?
REF1_lab
:REF<X>:LABel:DISPlay
Description
Turns the label on/off for the selected reference
waveform or returns its status.
Syntax
:REF<X>:LABel:DISPlay { OFF | ON | ? }
Related
commands
:REF<X>:LABel
Parameter
<X>
Reference waveform 1, 2, 3, 4
OFF
Turns the file label off for the selected
reference waveform.
ON
Turns the file label on for the selected
reference waveform.
Return parameter
Returns the status of the file label for the selected
reference waveform (ON, OFF).
