GW Instek GDS-1104B - Trigger:runt:polarity; Trigger:runt:when

COMMAND DETAILS
125
:TRIGger:RUNT:POLarity
Description
Sets or queries the Pulse Runt trigger polarity.
Syntax
:TRIGger:RUNT:POLarity { POSitive | NEGative |
EITher | ? }
Related
commands
:TRIGger:TYPe
Parameter
POSitive
Positive polarity
NEGative
Negative polarity
EITher
Positive or negative polarity
Return parameter
Returns the pulse runt trigger polarity.
Example
:TRIGger:RUNT:POLarity POSitive
Sets the Pulse Runt trigger polarity to positive.
:TRIGger:RUNT:WHEn
Description
Sets or queries the Pulse Runt trigger conditions.
Syntax
:TRIGger:RUNT:WHEn {MOREthan| LESSthan | EQual
| UNEQual | ? }
Related
commands
:TRIGger:TYPe
:TRIGger:RUNT:TIMe
Parameter
MOREthan
>
LESSthan
<
Equal
=
UNEQual
≠
Return parameter
Returns the pulse runt trigger condition.
Example
:TRIGger:RUNT:WHEn UNEQual
Sets the Pulse Runt trigger condition to unequal
(≠).
Set
Query
Set
Query
