Identifying IRF physical ports on the member switches
IMPORTANT:
For
the switch that provides 10-GE SFP+ ports, only the SFP+ ports can be used as IRF physical
ports when the switch runs Release 611x and Release 612x.
Identify the IRF physical ports on the member switches according to your topology and connection
scheme.
Table 8 shows the physical ports that can be used for IRF connection and the port use restrictions.
Table 8 IRF physical ports and use restrictions
Chassis Candidate IRF physical ports Use restrictions
S5560S-28S-SI
S5130S-28S-SI
S5130S-28S-LI
S5130S-28S-PWR-LI
S5560S-52S-SI
S5130S-52S-SI
S5130S-52S-LI
S5130S-52S-PWR-LI
S5500V3-24P-SI
S5500V3-48P-SI
All the following ports on the front
panel:
• 10/100/1000BASE-T
autosensing ports (supported
only in F6304 and later)
• SFP ports
• SFP+ ports
The port must operate at its highest
speed.
• 10/100/1000BASE-T autosensing
port—1 Gbps
• SFP port—1 Gbps
• SFP+ port—10 Gbps
For switches with 52 ports, these ports are
divided into two groups: ports 1 to 24, port
51, and port 52 in one group and ports 25
to 50 in the other group.
To bind multiple ports to an IRF port, make
sure the ports are in the same group.
Ports in one group can be bound to
different IRF ports.
The IRF physical ports on the member
switches must be same type.
S5560S-28F-SI
S5130S-28F-SI
S5130S-28S-HPWR-LI
All the following ports on the front
panel:
• 10/100/1000BASE-T
autosensing ports (supported
only in F6304 and later)
• SFP ports (supported only in
F6304 and later)
• SFP+ ports
The port must operate at its highest
speed.
• 10/100/1000BASE-T autosensing
port—1 Gbps
• SFP port—1 Gbps
• SFP+ port—10 Gbps
The IRF physical ports on the member
switches must be same type.
S5560S-52P-SI
S5120V2-52P-SI
S5120V2-52P-LI
S5120V2-52P-PWR-LI
S5110V2-52P-SI
S5048PV3-EI
S5048PV3-EI-PWR
All the following ports on the front
panel:
• 10/100/1000BASE-T
autosensing ports
• SFP ports
The port must operate at 1 Gbps.
The 52 GE ports are divided into two
groups: ports 1 to 24, port 51, and port 52
in one group and ports 25 to 50 in the
other group.
To bind multiple GE ports to an IRF port,
make sure the ports are in the same
group. GE ports in one group can be
bound to different IRF ports.
The IRF physical ports on the member
switches must be same type.
S3100V3-52TP-SI
The port must operate at 1 Gbps.
The 20 GE ports are divided into two
groups: ports 51 and 52 in one group and
ports 33 to 50 in the other group.
To bind multiple GE ports to an IRF port,
make sure the ports are in the same
