H3C S5000V3-EI User Manual

45
S5130S-28S-SI & S5130S-28S-LI
Figure 52 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP+ port LED
(4) System status LED (SYS)
(5) Micro USB console port
(6) Console port (CONSOLE)
(7) SFP+ port
Figure 53 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-52S-SI & S5130S-52S-LI
Figure 54 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Micro USB console port
(5) SFP+ port LED
(6) System status LED (SYS)
(7) SFP+ port
1
57
2
3
6
4
2
1
1
2
3
4
5
6
7
