Figure 45 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5560S-52S-SI
Figure 46 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) Micro USB console port
(5) SFP+ port LED
(6) System status LED (SYS)
(7) SFP+ port
Figure 47 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
2
1
1 2 3 4 5
6
7
1
2
