89
Management Ethernet port LED
The S5560S-28F-SI, S5560S-28DP-SI, and S5130S-28F-SI switches each provide a LED for the
management Ethernet port to indicate its operating status.
Table 33 Management Ethernet port LED description
Management Ethernet port LED (ACT/LINK) status Description
Steady green A link is present on the port.
Flashing yellow The port is sending or receiving data.
Off No link is present on the port.
Power module status LED
The S5560S-28F-SI, S5560S-28DP-SI, and S5130S-28F-SI switches each provide two power
module slots at the rear. For each power module, the switch provides a power module status LED on
the front panel.
Table 34 Power module status LED description
LED mark Status Description
PWR1/PWR1
Steady green
A power module is installed in the power module slot, and the power
module is outputting power correctly.
Steady yellow
A power module is installed in the power module slot, but the power
module is faulty or no power is being supplied to the power module.
Off No power module is installed in the power module slot.
RPS status LED
The S5130S-28S-HPWR-LI, S5130S-52S-PWR-LI, S5130S-28S-HPWR-LI, S5130S-52S-PWR-LI,
S5120V2-28P-HPWR-LI, S5120V2-52P-PWR-LI, S5024PV3-EI-HPWR, S5048PV3-EI-PWR, and
S3100V3-28TP-PWR-SI switches support RPS input. These switches except the
S5024PV3-EI-HPWR switch each provide an RPS status LED to indicate the power input status.
Table 35 RPS status LED description
LED mark Status Description
RPS
Steady green Both the RPS input and the AC input are normal.
Steady yellow Normal RPS input, no or abnormal AC input.
Off No or abnormal DC input.
Mode LED (MODE)
The mode LED works in conjunction with the 10/100BASE-T autosensing Ethernet port LEDs or
10/100/1000BASE-T autosensing Ethernet port LEDs to indicate the operating state of the
10/100BASE-T autosensing Ethernet port LEDs or 10/100/1000BASE-T autosensing Ethernet ports
and the switch.
You can use the LED mode switching button to change the indication of the mode LED.
