S3100V3-18TP-SI
Figure 106 Front panel
(1) 10/100BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port
(3) 10/100BASE-T autosensing Ethernet port LED
(4) 10/100/1000BASE-T autosensing Ethernet port LED
(5) SFP port LED
(6) System status LED (SYS)
(7) Console port (CONSOLE)
(8) SFP port
Figure 107 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S3100V3-28TP-SI
Figure 108 Front panel
(1) 10/100BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port
(3) 10/100BASE-T autosensing Ethernet port LED
(4) 10/100/1000BASE-T autosensing Ethernet port LED
(5) SFP port LED
(6) System status LED (SYS)
(7) Console port (CONSOLE)
(8) SFP port
1
3 4
5
2
6
8 7
1
2
1 3 4 52
6
8 7
