Figure 67 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
S5120V2-28P-SI & S5120V2-28P-LI
Figure 68 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure 69 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
