S5560S-52P-SI
Figure 42 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) SFP port LED
(5) System status LED (SYS)
(6) SFP port
Figure 43 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5560S-28S-SI
Figure 44 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP+ port LED
(4) System status LED (SYS)
(5) Micro USB console port
(6) Console port (CONSOLE)
(7) SFP+ port
1 2 3
6
5
4
1
2
1
57
2 3
6 4
