Table 36 Description for the mode LED
LED mark Status Description
Mode LED
(MODE)
Steady green The port LEDs are showing link state of the ports.
Flashing green
(Available only for
PoE switch models)
The port LEDs are showing the PoE status of the ports.
Flashing yellow
The port LEDs work in conjunction to indicate the IRF member ID
of the switch. For example, if the LED for port 5 is steady green,
the IRF member ID of the switch is 5.
SFP/SFP+ port LED
Table 37 SFP/SFP+ port LED description
Status Description
Steady green A link is present on the port.
Flashing green The port is sending or receiving data.
Off
• No link is present on the port.
• The mode LED is operating in IRF mode (available only for PoE switch
models and the S5560S-28DP-SI switch model)
• The mode LED is operating in PoE mode (available only for PoE switch
models)
10/100BASE-T autosensing Ethernet port LED and
10/100/1000BASE-T autosensing Ethernet port LED
On a PoE switch, the 10/100BASE-T autosensing Ethernet port LEDs or 10/100/1000BASE-T
autosensing Ethernet port LEDs work in conjunction with the mode LED to indicate the operating
state of the 10/100BASE-T autosensing Ethernet ports or 10/100/1000BASE-T autosensing
Ethernet ports and the switch from different aspects. See Table 38 for the LED description.
Among the non-PoE switch models, only the S5560S-28DP-S switch supports port LED mode
switching. The 10/100/1000BASE-T autosensing Ethernet port LEDs on the switch work in
conjunction with the mode LED to indicate the operating state of the 10/100/1000BASE-T
autosensing Ethernet ports and the switch from different aspects. See Table 38 for the LED
description.
Table 39 describes the 100/1000BASE-T autosensing Ethernet port LEDs and 10/100/1000BASE-T
autosensing Ethernet ports LEDs on non-PoE switches (except the S5560S-28DP-SI switch).
Table 38 10/100BASE-T autosensing Ethernet port LED and 10/100/1000BASE-T autosensing
Ethernet port LED description
Mode LED status
10/100BASE-T
autosensing Ethernet port
or 10/100/1000BASE-T
autosensing Ethernet port
LED status
Description
Steady green
(Link/Active mode)
Steady green A link is present on the port.
Flashing green The port is sending or receiving data.
