Appendix C Ports and LEDs
Ports
Console port
The S5560S-28S-SI switch, S5560S-52S-SI switch, S5560S-28F-SI switch, S5560S-28DP-SI,
S5130S-SI switch series, S5500V3-SI switch series, and S5130S-LI switch series provide a serial
console port and a micro USB console port on the front panel. The S5560S-28P-SI switch,
S5560S-52P-SI switch, S5120V2-SI switch series, S5120V2-LI switch series, S5110V2-SI switch
series, S5000V3-EI switch series, and S3100V3-SI switch series provide only a serial console port.
Table 24 Console port specifications
Item Serial console port Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an
ASCII terminal.
• Provides connection to the
serial port of a local PC running
terminal emulation program.
• Provides connection to an ASCII
terminal.
• Provides connection to the USB
port of a local PC running terminal
emulation program.
Management Ethernet port
The S5560S-28F-SI, S5560S-28DP-SI, and S5130S-28F-SI switches provide a management
Ethernet port on the front panel. You can connect this port to a PC or management station for loading
and debugging software or remote management.
Table 25 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Port attribute 10/100 Mbps, half/full duplex, MDI/MDI-X autosensing
Transmission medium Category-5 and above twisted pair cable
Max transmission distance 100 m (328.08 ft)
Compliant standard IEEE 802.3i, 802.3u, 802.3ab
Functions and services Software and Boot ROM upgrade and network management
USB port
An S5560S-28DP-SI switch provides one OHC-compliant USB 2.0 port that can upload and
download data at a rate up to 480 Mbps. You can use this USB port to access the file system on the
flash of the switch, for example, to upload or download application and configuration files.
