H3C S5000V3-EI

56
Figure 85 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5016PV3-EI
Figure 86 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure 87 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
1
2
1
2
3
4
6 5
1 2
