H3C S5130S-EI series Installation Guide

2-7
2 Installing the switch
CAUTION:
Keep the tamper
-
proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence.
Figure2-1 Hardware installation flow
Start
Install the switch
Ground the switch
Connect the power cords
Verify the installation
Turn on the circuit
breakers
Operating correctly
?
Turn off the circuit
breakers
Troubleshoot the
switch
No
Has power supply slots?
Yes
Select and install power
supplies
Yes
No
End
Connect interface cables

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
