H3C S5130S-EI series - S5130 S-52 P-Ei;S5130 S-52 P-Ei-M

2-22
Figure2-10 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-52P-EI/S5130S-52P-EI-M
Figure2-11 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) Console port (CONSOLE)
(4) SFP port LED
(5) System status LED (SYS)
(6) SFP port
Figure2-12 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
1
2
1 2 3 4
6 5
1
2
