2-42
Figure2-68 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-52ST-PWR-EI
Figure2-69 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP+ port
(4) Console port (CONSOLE)
(5) Port LED mode switching button
(6) Mode LED (MODE)
(7) System status LED (SYS)
(8) 10/5/2.5/1GBASE-T autosensing Ethernet port
(9) 10/5/2.5/1GBASE-T autosensing Ethernet port LED
(10) SFP+ port LED
Figure2-70 Rear panel
(1) AC-input power receptacle
(2) Grounding screw
1 2
1
2
3
4
5
10
7
6
9
8
21
