2 Chassis views
S5130S-10P-EI
Figure2-1 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure2-2 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5130S-12TP-EI
Figure2-3 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
1
3
2
4
5
6
21
1 2 3
45
6
