3 Removable components
WARNING!
Y
ou can replace one of the two power supplies operating in 1+1 redundancy on the S5130S-28F-
EI
and
S5130S-52F-EI switches. To avoid device damage and bodily injury, make sure the power
supply is powered off before removing it.
The S5130S-28F-EI and S5130S-52F-EI switches each provide two power supply slots. One power
supply can meet the power requirement of the switch. You can install two power supplies on the
switch for 1+1 redundancy. Table3-1 describes the power supplies available for the S5130S-52F-EI
switch.
Table3-1 Power supplies available for the S5130S-52F-EI switch
Power supply
model
Item Specification Remarks
PSR75-12A
Rated input voltage
AC: 100 VAC to 240 VAC
@ 50 Hz or 60 Hz
DC: 240 VDC
For more information about the
power supply, see H3C
PSR75-12A Power Module User
Manual.
Max input voltage
AC: 90 VAC to 290 VAC @
47 Hz to 63 Hz
DC: 180 VDC to 320 VDC
Max output power 75 W
PSR150-A1
Rated input voltage
100 VAC to 240 VAC @ 50
Hz or 60 Hz
For more information about the
power supplies, see H3C
PSR150-A & PSR150-D Series
Power Supplies User Manual.
Max input voltage
90 VAC to 264 VAC @ 47
Hz to 63 Hz
Max output power 150 W
PSR150-D1
Rated input voltage –48 VDC to –60 VDC
Max input voltage –36 VDC to –72 VDC
Max output power 150 W
