H3C S5130S-EI series Installation Guide

4-37
Table4-1 IRF physical ports and use restrictions
Device model
Candidate IRF physical
ports
Restrictions for using the ports for
IRF connections
S5130S-16S-PWR-EI
S5130S-16S-UPWR-EI-Q
S5130S-28S-EI
S5130S-28PS-EI
S5130S-28S-EI-M
S5130S-28S-EI-DP
S5130S-28S-PWR-EI
S5130S-28S-HPWR-EI
S5130S-28S-HPWR-EI-Q
S5130S-28S-UPWR-EI-Q
S5130S-28F-EI
S5130S-52S-EI
S5130S-52S-EI-M
S5130S-52S-PWR-EI
S5130S-52S-PWR-EI-AC
S5130S-52F-EI
All the following ports on the
front panel:
• SFP+ ports
• 10/100/1000BASE-T
autosensing ports
(supported only in
F6304 and later)
• SFP ports (supported
only in F6304 and later)
All physical ports to be bound to an IRF port
must have the same data rate.
The port must operate at its highest speed.
• SFP+ port—10 Gbps
• 10/100/1000BASE-T autosensing
port—1 Gbps
• SFP port—1 Gbps
For a 52-port switch model, the 52 ports are
divided into two groups: ports 1 to 24, port 51,
and port 52 in one group and ports 25 to 50 in
the other group.
To bind multiple ports to an IRF port, make
sure the ports are in the same group. Ports in
one group can be bound to different IRF ports.
S5130S-28MP-EI
S5130S-28MP-HPWR-EI
S5130S-52MP-EI
All the following ports on the
front panel:
• 5G/2.5G/1000BASE-T
autosensing Ethernet
ports
• 10/100/1000BASE-T
autosensing Ethernet
ports
• SFP ports
All physical ports to be bound to an IRF port
must have the same data rate.
The port must operate at its highest speed.
• 5G/2.5G/1000BASE-T autosensing
port—5 Gbps
• 10/100/1000BASE-T autosensing
port—1 Gbps
• SFP port—1 Gbps
For a 52-port switch model, the 52 ports are
divided into two groups: ports 1 to 24, port 51,
and port 52 in one group and ports 25 to 50 in
the other group.
To bind multiple ports to an IRF port, make
sure the ports are in the same group. Ports in
one group can be bound to different IRF ports.
S5130S-10MS-UPWR-EI
All the following ports on the
front panel:
• 2.5G/1000/100BASE-T
autosensing Ethernet
ports
• SFP+ ports
All physical ports to be bound to an IRF port
must have the same data rate.
The port must operate at its highest speed.
• 2.5G/1000/100BASE-T autosensing
port—2.5 Gbps
• SFP+ port—10 Gbps
S5130S-28ST-EI
S5130S-52ST-EI
S5130S-28ST-PWR-EI
S5130S-52ST-PWR-EI
All the following ports on the
front panel:
• 10/5/2.5/1GBASE-T
autosensing Ethernet
ports
• 10/100/1000BASE-T
autosensing Ethernet
ports
• SFP+ ports
All physical ports to be bound to an IRF port
must have the same data rate.
The port must operate at its highest speed.
• 10/5/2.5/1GBASE-T autosensing
port—10 Gbps
• 10/100/1000BASE-T autosensing
port—1 Gbps
• SFP+ port—10 Gbps
For a 52-port switch model, the 52 ports are
divided into two groups: ports 1 to 24, port 51,
and port 52 in one group and ports 25 to 50 in

H3C S5130S-EI series Specifications

General

Series	S5130S-EI
Category	Switch
MAC Address Table Size	16K
VLAN	4K VLANs
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T ports
Layer Support	Layer 3
Stacking	Supported
Power Supply	AC/DC
PoE	Supported on some models
Dimensions (W x D x H)	440 x 43.6 mm
