H3C S5500-EI Series Ethernet Switches
Chapter 3 Installation
3-30
1) Plug the DB-9 female connector of the console cable to the
serial port of the PC or terminal where the switch is to be
configured.
2) Connect the RJ-45 connector of the console cable to the
console port of the switch.
Caution:
Pay attention to the mark on the console port and be sure to plug the
connector to the right port.
Note:
z When connecting a PC to a powered-on switch, you are
recommended to connect the DB-9 connector of the console cable
to the PC before connecting the RJ-45 connector to the switch.
z When disconnecting a PC from a powered-on switch, you are
recommended to disconnect the DB-9 connector of the console
cable from the PC after disconnecting the RJ-45 connector from
the switch.
3.5 Installing and Removing Optional
Interface Modules
The S5500-EI series provide two 10 GE extended module slots
on the rear panel. You can select the following extended modules:
