H3C S5500-EI Series Ethernet Switches
Chapter 3 Installation
3-36
3.5.1 III. “Installation procedure” on page 3-32 and 3.5.1 IV. “Removal
procedure” on page
3-34 for it.
3.6 Installing and Removing the Dedicated
CX4 Cable
3.6.1 Installing the Dedicated CX4 Cable
 Note:
Make sure that you have installed a CX4 interface module before
installing the dedicated CX4 cable.
1) Wear an ESD-preventive wrist strap and verify the
ESD-preventive wrist strap properly grounded. Then take
out the dedicated CX4 cable from the package.
2) Horizontally insert the dedicated CX4 cable connector into
the CX4 port of the switch.
3.6.2 Removing the Dedicated CX4 Cable
1) Wear an ESD-preventive wrist strap and verify the
ESD-preventive wrist strap is properly grounded.
2) Hold the CX4 cable connector, pull the handle at the end of
the connector to horizontally unplug the CX4 cable
connector from the CX4 port.
