H3C S5500-EI Series User Manual

Quick Start
H3C S5500-EI Series Ethernet Switches
Chapter 3 Installation
3-2
Table 3-1 Installation methods for a switch with a width of 440
mm (17.3 in) or 436 mm (17.2 in.)
Method
Depth
Use
front
mounti
ng ears
Use front
and rear
mounting
ears
Use front
mounting
ears and a
tray
Use front
mounting
ears and
guide
rails
≤300 mm
(11.8 in)
√ — √ √
360 mm
(14.2 in.)
— √ √ √
420 mm
(16.5 in)
— √ √ √
 Note:
z When the depth of a switch is greater than 300 mm (11.8 in), the
front mounting ears only secure the switch rather than bear its
weight.
z Guide rails purchased from H3C apply only to standard cabinets
1,000 mm (39.4 in) deep. Use other supports to substitute for guide
rails in the case of other cabinet depths.
3.1.1 Introduction to Mounting Ears
Figure 3-1 shows the appearance of a front mounting ear.
