Quick Start
H3C S5500-EI Series Ethernet Switches
Chapter 3 Installation
3-13
Figure 3-11 Install front mounting ears
3) Install guide rails on the brackets on both sides of the
cabinet with M5 self-tapping screws, as shown in
Figure
3-12.
Figure 3-12 Install guide rails
