77
USB port
The switch has one OHC-compliant USB2.0 port that can upload and download data at a rate up to 480
Mbps. You can use this USB port to access the file system on the flash of the switch, for example, to
upload or download application and configuration files.
NOTE:
USB devices from different vendors vary in compatibilities and drivers. H3C does not
uarantee the correc
operation of USB devices from all vendors on the switch. If a USB device fails to operate on the switch,
replace it with one from another vendor.
10/100/1000BASE-T autosensing Ethernet port
Table 20 10/100/1000BASE-T autosensing Ethernet port specifications
Item Specification
Connector type
RJ-45
Interface attributes
• 10 Mbps, full duplex
• 100 Mbps, full duplex
• 1000 Mbps, full duplex
• MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.08 ft)
Transmission medium
Category-5 (or above) twisted pair cable
Standards
IEEE 802.3i, 802.3u, 802.3ab
1/10BASE-T autosensing Ethernet port
The LSWM2XGT2PM and LSWM2XGT8PM interface cards provide 1/10BASE-T autosensing Ethernet
ports.
Table 21 1/10BASE-T autosensing Ethernet port specifications
Item Specification
Connector type
RJ-45
Interface attributes 1/10 Gbps, full duplex, MDI/MDI-X auto-sensing
Max transmission
distance
• Category-6 UTP—55 m (180.45 ft)
• Category-6 STP—100 m (328.09 ft)
• Category-6 SFTP—100 m (328.09 ft)
• Category-6 and above twisted pair—100 m (328.09 ft)
Transmission medium
Category-6 (or above) twisted pair cable
Standards
IEEE 802.3an, 802.3ab
