H3C S5560-EI series User Manual

85
10/100/1000BASE-T autosensing Ethernet port LED
The switch provides a status LED for each 10/100/1000BASE-T autosensing Ethernet port. The port LED
and the MODE LED work in conjunction to indicate the operating status of the 10/100/1000BASE-T
autosensing Ethernet port.
Table 33 10/100/1000BASE-T autosensing Ethernet port LED description
MODE LED status
10/100/1000BASE-T
autosensing Ethernet
port LED status
Description
Steady green (rate mode)
Steady green
A link is present on the port and the port is operating
at 1000 Mbps.
Flashing green The port is sending or receiving data at 1000 Mbps
Steady yellow The port is operating at 10/100 Mbps.
Flashing yellow
The port is sending or receiving data at 10/100
Mbps
Flashing yellow (3 Hz) The port has failed POST.
Off No link is present on the port.
Flashing green (1 Hz) (PoE
mode, available only for
S5560-30C-PWR-EI and
S5560-54C-PWR-EI
switches)
Steady green PoE power supply is normal.
Flashing green (3 Hz)
The device attached to the port requires power
higher than the maximum or currently available PoE
output power on the port.
Steady yellow The port is experiencing a PoE failure.
Flashing yellow (3 Hz) The port has failed POST.
Off The port is not supplying power through PoE.
Flashing yellow (IRF mode) Steady green
The port status LEDs on the switch work in
conjunction to indicate the IRF member ID of the
switch. For example, if the LEDs for ports 1 to 5 are
steady green and the other port LEDs are off, the IRF
member ID of the switch is 5.
100/1000Base-X SFP port LED
On the S5560-30F-EI and S5560-34C-EI switches, the SFP port LED and the MODE LED work in
conjunction to indicate the operating status of the SFP port.
Table 34 100/1000Base-X SFP port LED description
MODE LED status
SFP port LED status Description
Steady green (rate
mode)
Steady green
A link is present on the port and the port is operating at 1000
Mbps.
Flashing green The port is sending or receiving data at 1000 Mbps.
Steady yellow
A link is present on the port and the port is operating at 100
Mbps.
