H3C S5560-EI series User Manual

71
You can install one power module, or two power modules for redundancy on the S5560-30C-PWR-EI
and S5560-54C-PWR-EI switches. The PoE capabilities of these switches vary by power module
configuration. For more information, see Table 12.
A
ll S5560-EI switch models except the S5560-30S-EI and S5560-54S-EI switches support hot swapping
of fan trays. You must install two fan trays of the same model for the switch. Do not power on the switch
when it does not have any fan trays or has only one fan tray installed.
Support for the LSPM6G4T6P and LSPM6FWD cards varies by software version. For more information,
see the release notes for the switch.
Hot-swappable power modules
All S5560-EI switch models except the S5560-30S-EI and S5560-54S-EI switches support hot swapping
of power modules. The following table describes power modules available for the switch.
Table 14 Hot-swappable power modules
Power module Specifications Reference
PSR150-A1
• Rated input voltage range: 100 VAC to
240 VAC @ 50 Hz or 60 Hz
• Max input voltage range: 90 VAC to
264 VAC @ 47 Hz to 63 Hz
• Max output power: 150 W
H3C PSR150-A & PSR150-D Series
Power Modules User Manual
PSR150-D1
• Rated input voltage range: –48 VDC to
–60 VDC
• Max input voltage range: –36 VDC to
–72 VDC
• Max output power: 150 W
H3C PSR150-A & PSR150-D Series
Power Modules User Manual
PSR360-56A
• Rated input voltage range: 100 VAC to
240 VAC @ 50 Hz or 60 Hz
• Max input voltage range: 90 VAC to
264 VAC @ 47 Hz to 63 Hz
• Max output power: 360 W
H3C PSR360-56A Power Module
User Manual
PSR720-56A
• Rated input voltage range: 100 VAC to
240 VAC @ 50 Hz or 60 Hz
• Max input voltage range: 90 VAC to
264 VAC @ 47 Hz to 63 Hz
• Max output power: 720 W
H3C PSR720-56A Power Module
User Manual
PSR1110-56A
• Rated input voltage range: 115 VAC to
240 VAC @ 50 Hz or 60 Hz
• Max input voltage range: 102.5 VAC
to 264 VAC @ 47 Hz to 63 Hz
• M a x o u t p u t p o w e r : 1110 W
H3C PSR1110-56A Power Module
User Manual
NOTE:
The PSR1110-56A power module adds 64 mm (2.52 in) to the depth of the switch, includin
g
the depth of
the power module handle.
