H3C S5560-EI series User Manual

67
Item S5560-34C-EI S5560-54C-EI S5560-54QS-EI
ports form combo
interfaces.)
Expansion
slots
1, on the rear panel 1, on the rear panel N/A
Power module
slots
2, on the rear panel 2, on the rear panel 2, on the rear panel
Fan tray slots 2, on the rear panel 2, on the rear panel 2, on the rear panel
Input voltage
• AC-input
{ Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• DC-input
{ Rated voltage range: –48 VDC to –60 VDC
{ Max voltage range: –36 VDC to –72 VDC
NOTE:
You can use the site –48 VDC power source or an H3C RPS800-A or RPS1600-A RPS as the DC
power source.
Minimum
power
consumption
• Single AC input: 41 W
• Single DC input: 43 W
• Dual AC inputs: 44 W
• Dual DC inputs: 49 W
• Single AC input: 70 W
• Single DC input: 70 W
• Dual AC inputs: 59 W
• Dual DC inputs: 59 W
• Single AC input: 88 W
• Single DC input: 85 W
• Dual AC inputs: 77 W
• Dual DC inputs: 75 W
Maximum
power
consumption
• Single AC input: 107
W
• Single DC input: 107
W
• Dual AC inputs: 111 W
• Dual DC inputs: 115 W
• Single AC input: 123
W
• Single DC input: 123
W
• Dual AC inputs: 127 W
• Dual DC inputs: 130 W
• Single AC input: 112 W
• Single DC input: 112 W
• Dual AC inputs: 116 W
• Dual DC inputs: 120 W
Chassis
leakage
current
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Melting current
of power
module fuse
• AC-input: 5 A, 250V
• DC-input: 8 A, 250V
• AC-input: 5 A, 250V
• DC-input: 8 A, 250V
• AC-input: 5 A, 250V
• DC-input: 8 A, 250V
Operating
temperature
0°C to 45°C (32°F to 113°F)
Relative
humidity
5% to 95%, noncondensing
Fire resistance
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Table 12 Technical specifications for PoE switch models
Item S5560-30C-PWR-EI S5560-54C-PWR-EI
Dimensions (H × W
× D)
43.6 × 440 × 460 mm 43.6 × 440 × 460 mm
