H3C S5560-EI series User Manual

66
Item S5560-30S-EI S5560-54S-EI S5560-30F-EI S5560-30C-EI
power
consumption
•
DC: 68 W
•
DC: 82 W
12 0
W
• Single DC input:
123 W
• Dual AC inputs:
14 6 W
• Dual DC inputs:
133 W
input: 107 W
• Single DC
input: 108 W
• Dual AC inputs:
111 W
• Dual DC inputs:
115 W
Chassis
leakage
current
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Melting current
of power
module fuse
• AC-input: 3.15 A,
250 V
• DC-input: 8 A,
250 V
• AC-input: 3.15
A, 250 V
• DC-input: 8 A,
250 V
• AC-input: 5 A, 250
V
• DC-input: 8 A, 250
V
• AC-input: 5 A,
250 V
• DC-input: 8 A,
250 V
Operating
temperature
0°C to 45°C (32°F to 113°F)
Relative
humidity
5% to 95%, noncondensing
Fire resistance
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Table 11 Technical specifications for non-PoE switch models (2)
Item S5560-34C-EI S5560-54C-EI S5560-54QS-EI
Dimensions (H
× W × D)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17 in)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17 in)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17 in)
Weight ≤ 7.5 kg (16.53 lb) ≤ 7.5 kg (16.53 lb) ≤ 7.5 kg (16.53 lb)
Console ports
• 1 × Mini USB console port
• 1 × serial console port
Only the Mini USB console port is available when you connect both ports.
USB ports 1 1 1
Management
Ethernet ports
1 1 2
QSFP+ ports N/A N/A 2
SFP+ ports 4 4 4
SFP ports
8 (Each and its
corresponding
10/100/1000BASE-T
autosensing Ethernet port
form a combo interface.)
N/A N/A
10/100/100
0Base-T
autosensing
Ethernet ports
28 (The rightmost eight
10/100/1000BASE-T
autosensing Ethernet ports
and their corresponding SFP
48 24
