H3C S5560-EI series User Manual

65
Item S5560-30S-EI S5560-54S-EI S5560-30F-EI S5560-30C-EI
× W × D) mm (1.72 × 17.32
×10.24 in)
mm (1.72 × 17.32
×10.24 in)
(1.72 × 17.32 ×
14.17 in)
mm (1.72 × 17.32 ×
14.17 in)
Weight ≤ 5 kg (11.02 lb) ≤ 5 kg (11.02 lb) ≤ 7.5 kg (16.53 lb) ≤ 7.5 kg (16.53 lb)
Console ports
• 1 × Mini USB console port
• 1 × serial console port
Only the Mini USB console port is available when you connect both ports.
USB ports 1 1 1 1
Management
Ethernet ports
N/A N/A 1 1
QSFP+ ports 2 2 N/A N/A
SFP+ ports 4 4 4 4
SFP ports N/A N/A
24 (The rightmost
eight SFP ports and
their corresponding
10/100/1000BAS
E-T autosensing
Ethernet ports form
combo interfaces.)
N/A
10/100/100
0BASE-T
autosensing
Ethernet ports
24 48
8 (Each and its
corresponding SFP
port form a combo
interface.)
24
Expansion
slots
N/A N/A 1, on the rear panel 1, on the rear panel
Power module
slots
N/A N/A 2, on the rear panel 2, on the rear panel
Fan tray slots N/A N/A 2, on the rear panel 2, on the rear panel
Input voltage
• AC-input
{ Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• DC-input
{ Rated voltage range: –48 VDC to –60 VDC
{ Max voltage range: –36 VDC to –72 VDC
NOTE:
You can use the site –48 VDC power source or an H3C RPS800-A or RPS1600-A RPS as the DC
power source.
Minimum
power
consumption
• AC: 42 W
• DC: 40 W
• AC: 52 W
• DC: 52 W
• Single AC input:
48 W
• Single DC input:
53 W
• Dual AC inputs:
70 W
• Dual DC inputs:
60 W
• Single AC
input: 55 W
• Single DC
input: 57 W
• Dual AC inputs:
49 W
• Dual DC inputs:
51 W
Maximum
• AC: 66 W • AC: 80 W
• Single AC input: • Single AC
